Responsive Header

This project showcases an example of how to build a Reusable Component for Responsive Web.

External Dependencies

This project uses AmplifyJs's core module. This is bundled within the component so once the component is imported this Javascript module will be added to the project's global modules directory.

Implementation Notes

This component was built using Kony Visualizer Enterprise 8.4.6.

Responsiveness

In a Kony responsive web application, changing the width of the browser will fire the FlexForm's onBreakpointChange event handler. From there, in order to also notify any component instances in the form of this event, the FlexForm's event handler could directly invoke a custom method in each component that's meant to be responsive -e.g.:

// A tightly coupled form controller.
define({
  onBreakpointChange: function(form, width) {
    this.view.FooComponent.adjust(width);
    this.view.BarComponent.adjust(width);
    // For each and every component in the form.
    this.view.QuxComponent.adjust(width);
  },
  onNavigate: function() {
    this.view.onBreakpointChange = this.onBreakpointChange;
  }
});

The down-side with this approach is two-fold. First, it forces you to expose this hypothetical custom adjust method for each component.

Second, it tightly couples the form controller to the components. You have to call this hypothetical custom adjust method for each and every component in the form and add or remove calls as you add or remove components to it, resulting in less maintainable codebase.

We can do better...

Instead of that, this project uses the Publish-Subscribe Pattern, by leveraging AmplifyJs's core module to achieve low coupling between each form and the instances of the components inside it. This way, the form's controller stays lean and you do not need to update it to keep it in sync with whatever components you've added to it. Here's an example in a standard barebones form controller:

//A loosely coupled form controller.
define({
  onBreakpointChange: function(form, width) {
    amplify.publish("onBreakpointChange", form, width);
  },
  onNavigate: function() {
    this.view.onBreakpointChange = this.onBreakpointChange;
  }
});

Then, each component just listens for the onBreakpointChange event using AmplifyJs as well:

//A loosely coupled component controller.
constructor: function(baseConfig, layoutConfig, platformSpecificConfig) {
	//Then let's subscribe to the form's onBreakpointChange.
	amplify.subscribe(
		"onBreakpointChange", //topic
		this, //context
		this.onBreakpointChange, //callback
		1 //priority
	);
},
onBreakpointChange: function(form, width){
	// Here we adjust whatever widgets need to be resized,
	// repositioned, made visible/invisible or re-skinned
	// depending on the new screen width.
},

Components implemented like this can be seamlessly added to a form, without the need to expose additional custom methods and without having to code additional invocations in the form's controller.
